SAK terminals

Mark Stand Universal Type Universal Type
SAK-B JXB-B SAK 2.5EN JXB2.5/35 SAK 4EN JXB 4/35
 Rated section 0.5-2.5mm2 0.2-4mm2
Rated voltage / Rated current   Current: 24A Voltage: 800V Current: 32A Voltage: 800V
End cover: Thick1.5mm AP2.5 AP4
Center connection piece: 10 position.  2.5Q 2-10 4ENQ 2-10
can be divided into 2, 3 or 10 position
Universal End Fixed Piece EW35 EW35



Mark Stand Universal Type Universal Type Universal Type
SAK-B JXB-B SAK 6EN JXB6/35 SAK 10EN  JXB10/35 SAK 16EN JXB16/35
 Rated section 0.2-6mm2 0.2-10mm2 0.5-16mm2
Rated voltage / Rated current   Current: 41A Voltage: 800V Current: 57A Voltage: 800V Current: 76A Voltage: 800V
End cover: Thick1.5mm AP6 AP10 AP16
  6ENQ2-10 10ENQ2-10 16ENQ2-10
Universal End Fixed Piece EW35 EW35 EW35



Mark Stand Universal Type Universal Type Double Level Type
SAK-B JXB-B SAK 35EN JXB2.35 SAK 70EN JXB70/35 DK 4Q/35 JXB-4/35S1
 Rated section 10-35mm2 25-70mm2 0.2-4mm2
Rated voltage / Rated current   Current: 125A Vltage: 800V Current: 192A Voltage: 800V Current: 32A Voltage: 50V
End cover: Thick1.5mm AP35 AP70/35 AP-DK4
can be divided into 2, 3 or 10 position 35Q2-10 2.5Q2-10 DK4Q2-10
Universal End Fixed Piece EW35 EW35 EW35



Mark Stand Double Level Type Fuse Type Test Type
SAK-B JXB-B DK4QV/35 JXB-4/35SZ1 SAK RD LTU4-RD(JXB RD) SAK WL 6/1S  JXB-WL6/1
Rated section 0.2-4mm2 0.2-4mm2 0.2-4mm2
Rated voltage / Rated current Current: 32A Voltage: 500V Current: 6.3A Voltage: 500V Current: 41A Voltage: 400V
End cover: Thick1.5mm AP-DK4 AP1.5 WAP-WTL4
can be divided into 2, 3 or 10 position AP-DK4 2-10 / WTL2-10
Universal End Fixed Piece EW35 EW35 EW35
