Quick Connector 73 Series
| Item.No |
102A |
| Rated voltage |
400V |
| Rated current |
24A |
| Wire diameter |
0.75-2.5mm2/18-13AWG |
| Strip length |
10mm/0.4in |
| Quantity |
10pcs |
| Dimension |
19.5x13.1x9.2(mm) |
| (LxWxH) |
| Item.No |
104A |
| Rated voltage |
400V |
| Rated current |
24A |
| Wire diameter |
0.75-2.5mm2/18-13AWG |
| Strip length |
10mm/0.4in |
| Quantity |
10pcs |
| Dimension |
19.5x13x13.1mm |
| (LxWxH) |
| Item.No |
106A |
| Rated voltage |
400V |
| Rated current |
24A |
| Wire diameter |
0.75-2.5mm2/18-13AWG |
| Strip length |
10mm/0.4in |
| Quantity |
5pcs |
| Dimension |
19.5x18.8x13.1mm |
| (LxWxH) |
| Item.No |
108A |
| Rated voltage |
400V |
| Rated current |
24A |
| Wire diameter |
0.75-2.5mm2/18-13AWG |
| Strip length |
10mm/0.4in |
| Quantity |
5pcs |
| Dimension |
19.5x24x13.1mm |
| (LxWxH) |
| Item.No |
101A |
| Rated voltage |
400V |
| Rated current |
24A |
| Wire diameter |
1.0-2.5mm2(Round hole:BV ) |
| 0.5-2.5mm2(Square hole:BV or RV) |
| Strip length |
11mm/0.46in |
| Quantity |
10pcs |
| Dimension |
20.5x8.5x15.5mm |
| (LxWxH) |
| Item.No |
112A |
| Rated voltage |
400V |
| Rated current |
24A |
| Wire diameter |
1.0-2.5mm2(Round hole:BV ) |
| 0.5-2.5mm2(Square hole:BV or RV) |
| Strip length |
11mm/0.46in |
| Quantity |
10pcs |
| Dimension |
20.5x10x15.5mm |
| (LxWxH) |
