| Technical parameters | |||||||||
Type |
Maximum air flow(m3/h) | Rated voltage(V) | Frequency(Hz) | Noise DB(A) | Current(AMP) | Power(Watt) | Speed(min) | Ambient temperature(℃) | Weight(g) |
| 200FZY2-D | 780 | 220 | 50 | 67 | 1.0/400V | 65 | 2800 | -20.. 80 | 1430 |
| 200FZY4-D | 780 | 380 | 50 | 67 | 3P | 65 | 2800 | -20.. 80 | 1430 |
| 200FZY7-D | 800 | 380 | 50 | 67 | 1.0/630V | 65 | 2800 | -20.. 80 | 1430 |
Motor:squirrel cage motor structure.Impedance protection.
Withstanding Voltage:Voltage leakage 0.5mA,withstand voltage 1500V/min.
Insulation Class B,protection class IP54.
Fan rotation:counter-clockwise as viewed from the direction of the blades
