Technical parameters | |||||||||
Type | Maximum air flow(m3/h) | Ratedvoltage(V) | Frequency(Hz) | Noise DB(A) | Current(AMP) | Power(Watt) | Speed(min) | Ambient temperature(℃) | Weight(g) |
18060HBL2 | 600 | 230 | 50 | 53 | 0.35 | 58 | 2500 | -20.. 80 | 1580 |
18060HBL3 | 600 | 380 | 50 | 53 | 0.25 | 60 | 2500 | -20.. 80 | 1580 |
Motor:shaded pole motor structure.Impedance protection.
Withstanding Voltage:Voltageleakage 0.5mA,withstand voltage 1800V/min.
Insulation Class B,protection class IP54.
Fan rotation:counter-clockwise as viewedfrom the direction of the blades
