Type |
Maximum air flow(m3/h) | Rated voltage(V) | Frequency(Hz) | Noise DB(A) | Ball bearing(B) | Bearings（S） | Power(Watt) | Speed(min) | Ambient temperature(℃) | Weight(g) |
| 125FZY2-S | 225 | 220 | 50 | 45 | S | 22 | 2350 | -10.. 70 | 260 | |
| 125FZY2-S | 230 | 220 | 50 | 45 | B | 22 | 2400 | -20.. 80 | 260 | |
|
125FZY4-S |
225 | 380 | 50 | 45 | S | 22 | 2350 | -10.. 70 | 260 | |
| 125FZY4-S | 230 | 380 | 50 | 45 | B | 22 | 2400 | -20.. 80 | 260 |
Motor:shaded pole motor structure.Impedance protection.
Withstanding Voltage:Voltageleakage 0.5mA,withstand voltage 1800V/min.
Insulation Class B,protection class IP54.
Fan rotation:counter-clockwise as viewedfrom the direction of the blades
