| Technical parameters | |||||||||
| Type | Maximum air flow(m3/h) | Ratedvoltage(V) | Frequency(Hz) | Noise DB(A) | Current(AMP) | Power(Watt) | Speed(min) | Ambient temperature(℃) | Weight(g) |
| 20060HBL2 | 680 | 230 | 50 | 56 | 0.45 | 65 | 2500 | -20.. 80 | 1600 |
| 20060HBL3 | 680 | 380 | 50 | 56 | 0.28 | 68 | 2500 | -20.. 80 | 1600 |
Motor:shaded pole motor structure.Impedance protection.
Withstanding Voltage:Voltageleakage 0.5mA,withstand voltage 1800V/min.
Insulation Class B,protection class IP54.
Fan rotation:counter-clockwise as viewedfrom the direction of the blades
